Specifications & Key Features

• Motor Power (range) — Available from 1.5 kW to 75 kW+ (2–100 HP) to suit lab, pilot and large production vessels.
• Speed Range & Control — Stepless control typically 50–3000 RPM with VFD for precise shear and gentle mixing profiles.
• High Torque Gearbox — Helical/planetary gearbox options delivering high torque at low speeds for viscous and high-load applications.
• Top-Entry Shaft & Impellers — Hardened stainless-steel shaft (Ø 30–100 mm) with interchangeable impellers (turbine, anchor, gate, high-shear rotor/stator).
• Mounting & Flange Interface — Standard top flange or skirt-mounted head for direct vessel installation; anti-vibration mounts and torque arm options.
• Sealing Options — Mechanical seals, stuffing box, or pressurized gland arrangements with barrier/flush for abrasive or sanitary services.
• Wetted Materials & Finish — SS316/SS316L wetted parts, sanitary polish options, and special coatings available for corrosive or food/pharma use.
• Instrumentation & Controls — Integrated control panel/PLC, torque/load monitoring, soft-start, emergency stop, and optional automated speed/position presets.
• Serviceability & Safety — Modular head design for easy removal, greaseable bearings, isolation flanges, guard/interlocks and compliant with CE/UL standards.
• Applications & Performance — Optimized for large-volume dispersion, emulsification, homogenization and heat transfer in paints, coatings, adhesives, cosmetics, food and pharmaceutical processes; available with sanitary and ATEX variants.

Advantages

• Efficient high-volume mixing — Ideal for large tanks and continuous production with uniform dispersion and faster processing.
• Powerful torque & speed control — Handles low to high viscosity materials with smooth operation through VFD control.
• Easy integration & installation — Mounts directly on tank tops, saving floor space and simplifying plant layout.
• Low maintenance & durable design — Robust gearbox, stainless construction, and accessible components ensure long service life.
• Versatile process capability — Suitable for dispersion, emulsification, and homogenization across chemical, paint, adhesive, and cosmetic industries.

Applications

• Paints & Coatings — Effective dispersion of pigments, fillers, and resins for smooth, consistent product quality.
• Adhesives & Sealants — Uniform blending of polymers, additives, and thickeners for stable bonding formulations.
• Cosmetics & Personal Care — Mixing creams, lotions, gels, and emulsions with smooth texture and homogeneity.
• Chemicals & Petrochemicals — Processing emulsions, suspensions, and polymer dispersions in large-scale reactors.
• Food & Pharmaceutical — Hygienic mixing of sauces, syrups, and liquid formulations under sanitary conditions.
