Laboratory Agitator
(Gear Drive Stirrer, Low Speed Stirrer)
.
Artisan Laboratory Agitator with Gear Drive is specially designed for low-speed mixing applications requiring high torque. Equipped with a durable gear transmission system, it enables efficient stirring of viscous liquids, slurries, and suspensions, making it ideal for research, quality control, and development laboratories. The stirrer features a robust stainless steel shaft and impeller, with adjustable speed control for precise process management.
Its compact design includes an ergonomic stand with height adjustment, ensuring adaptability to various vessel sizes. The gear-driven mechanism offers smooth, consistent mixing with minimal maintenance. This agitator is essential for delivering reliable, reproducible results in demanding laboratory environments focused on product formulation, testing, and innovation
Models & Data Sheet
| Model | Motor Power Watt (HP) | Speed @50 Hz (RPM) | Motor Type | Mixing Capacity (L) |
|---|---|---|---|---|
| AP-1 | 180 (1/4) | 10-200 | PMDC Motor | 5-10 |
| AP-2 | 370 (1/2) | 10-200 | PMDC Motor | 10-20 |
| AA-0.5 | 120 (1/6) | 10-200 | AC Induction Motor | 5-15 |
| AA-25 | 180 (1/4) | 10-200 | AC Induction Motor | 10-40 |
| AA-2 | 370 (1/2) | 10-200 | AC Induction Motor | 10-60 |
Specifications & Key Features
- Motor Power (range) — Available from 0.5 HP to 5 HP, ideal for lab-scale and pilot applications.
- Speed Range — Low-speed operation 10–500 RPM for high-viscosity and shear-sensitive materials.
- Gear Drive System — Precision helical or worm gearbox ensures smooth torque transmission and stable operation.
- Top-Entry Design — Mounts directly on laboratory or pilot tanks for convenient, space-saving use.
- Impeller Options — Interchangeable impellers such as anchor, paddle, or helical ribbon for versatile mixing.
- Material of Construction — SS304/SS316 wetted parts and robust frame for corrosion resistance and durability.
- Manual or Adjustable Lifting — Handwheel or crank system for precise vertical adjustment of the shaft.
- Control & Safety Features — Start/stop switch, VFD option, emergency stop, and overload protection for safe operation.
- Maintenance & Serviceability — Modular design with easy access to bearings, seals, and impellers for low downtime.
- Applications & Performance — Suitable for paints, adhesives, coatings, cosmetics, food, and pharmaceutical formulations; ensures uniform mixing, low shear blending, and efficient homogenization.
Advantages
- Efficient low-speed mixing — Ideal for high-viscosity and shear-sensitive liquids.
- Precise torque transmission — Gear drive ensures stable operation and consistent results.
- Versatile impeller options — Supports anchor, paddle, and helical ribbon impellers for different applications.
- Durable & low-maintenance — SS304/SS316 construction with easy-access components reduces downtime.
- Compact and user-friendly — Top-entry design with manual lifting for flexible lab or pilot use.
Applications
- Paints & Coatings — Uniform blending of pigments, resins, and additives for smooth, high-quality formulations.
- Adhesives & Sealants — Efficient mixing of polymers, thickeners, and additives in viscous liquids.
- Cosmetics & Personal Care — Homogenizing creams, lotions, gels, and emulsions with minimal shear.
- Food & Beverages — Gentle mixing of sauces, syrups, and viscous liquid ingredients for lab-scale batches.
- Pharmaceuticals & Chemicals — Blending of high-viscosity solutions, suspensions, and chemical formulations for research and pilot applications.
